Most developers are used to spinning up a single instance of their database system and calling it a day. But what happens when you need true redundancy? How do you ensure that a hardware failure doesn’t wipe out your latest transactions?

Today, we are experimenting with database replication using MariaDB and Galera Cluster.

Galera allows us to set up a “multi-master” environment. This means we can treat a group of servers as one giant super-database. It offers synchronous replication (so data is consistent across all nodes) and automatic node joining.

We are going to simulate a production-style environment right on our local machine. We will:

1. Provision three Debian virtual machines.

2. Network them together to form a private mesh.

3. Bootstrap a Galera Cluster.

4. Throw traffic at it with a Node.js load balancer to see the magic in action.

Step 1: Create a Host-only Network

First, we need to create a private network. This allows our virtual machines to communicate with one another (and our host machine) without exposing their internal replication traffic to the outside world.

1. Open VirtualBox.

2. In the left sidebar, click the Tools menu icon (the hamburger menu) and select Network.

3. Click the Host-only Networks tab.

4. If a network already exists, you can use it. If not, click Create to generate a new one.

5. Select the adapter you just created and ensure the Adapter tab is configured manually with the following settings:

   1. IPv4 Address: 192.168.56.1

   2. IPv4 Network Mask: 255.255.255.0

6. Click Apply.

Note: We will configure the IP addresses for the individual nodes manually inside Debian later, so you don’t need to worry about the DHCP server settings here.

Step 2: Create the First Node (“galera-alpha”)

We will create our first node, install the operating system, and configure it to serve as a template for the other two.

VirtualBox Configuration

1. In VirtualBox, click Machine > New.

2. Name: galera-alpha.

3. ISO Image: Select the latest Debian ISO image. You can download it from https://debian.org

4. Unattended Install: Check the box for Skip Unattended Installation. This is important; we want to configure the hostname and user manually.

5. Hardware:

   1. Base Memory: 2048 MB is sufficient, but more is better if you can spare.

   2. Processors: 2 CPUs are sufficient, but again, more is better.

   3. Hard Disk: The 20 GB default is fine

6. Click Finish to create the VM container.

Configure Networking

Before powering on, we need to set up the dual-network architecture: Adapter 1 for internet access (downloading packages) and Adapter 2 for our private cluster traffic.

1. Right-click galera-alpha and choose Settings.

2. Go to the Network section.

3. Adapter 1: Ensure Enable Network Adapter is checked and Attached to is set to NAT.

4. Adapter 2: Check Enable Network Adapter and set Attached to to Host-only Adapter.

   1. Name: Select the network we created in Step 1.

Operating System Installation

1. Power on the virtual machine.

2. Follow the standard Debian installer prompts. Choose the defaults or whichever options make sense for you.

3. Network Configuration: When asked to choose the primary network interface, select the first one (usually enp0s3) to ensure the installer can reach the internet.

4. Hostname: galera-alpha

5. Domain name: local (or anything you want, as long as all nodes we will create match)

6. Software Selection: When you reach the software selection screen:

   1. Uncheck Debian desktop environment and GNOME (we want a headless server).

   2. Check SSH server and standard system utilities.

7. Finish the installation and allow the VM to reboot.

8. Once the login prompt appears, power off the virtual machine. We are now ready to clone it.

Step 3: Clone the Nodes

Now that we have a fresh base installation, we will clone it to create our second and third nodes.

1. In VirtualBox, right-click galera-alpha and select Clone.

2. Name: galera-beta

3. MAC Address Policy: Select Generate new MAC addresses for all network adapters. Critical: If you miss this step, your routers will see identical MAC addresses and the networking will fail.

4. Click Finish.

5. Repeat the process to create galera-gamma.

Step 4: Configure Hostnames and IPs

We now have three identical servers. We need to give them unique identities and assign static IP addresses to the private network interface (Adapter 2).

1. Start all three virtual machines.

2. Log in as root on each machine.

Set Hostnames

Run the following command on the respective nodes to set their system hostnames:

• Node 2: hostnamectl set-hostname galera-beta

• Node 3: hostnamectl set-hostname galera-gamma

Note: galera-alpha should already be set from the installation step.

Configure Static IPs

We need to configure the second network interface (usually enp0s8) with a static IP.

1. Verify your interface name by running ip link. You are looking for the interface that is down or has no IP (likely the second one listed).

2. Edit the network configuration file, /etc/network/interfaces.

3. Append the configuration for the specific node:

# On galera-alpha
allow-hotplug enp0s8
iface enp0s8 inet static
    address 192.168.56.101
    netmask 255.255.255.0

# On galera-beta
allow-hotplug enp0s8
iface enp0s8 inet static
    address 192.168.56.102
    netmask 255.255.255.0

# On galera-gamma
allow-hotplug enp0s8
iface enp0s8 inet static
    address 192.168.56.103
    netmask 255.255.255.0

3. Apply the changes by restarting the networking service on all nodes: systemctl restart networking

Update the Hosts File

To make communication easier (so we don’t have to remember IPs), we will map the hostnames in the /etc/hosts file.

Edit /etc/hosts on all three nodes and append the following lines to the bottom:

192.168.56.101 galera-alpha
192.168.56.102 galera-beta
192.168.56.103 galera-gamma

Install Software

Finally, install the database server and rsync (which Galera uses the synchronize data between nodes) on all three nodes:

apt install -y mariadb-server rsync

Step 5: Configure MariaDB for Galera Cluster

We need to tell MariaDB how to communicate with its peers.

Edit /etc/mysql/mariadb.conf.d/60-galera.cnf. Make sure these settings are set on all three nodes.

wsrep_on = ON
wsrep_cluster_name = "GaleraCluster" # Give it any name you want
wsrep_cluster_address = "gcomm://192.168.56.101,192.168.56.102,192.168.56.103"
binlog_format = row
default_storage_engine = InnoDB
innodb_autoinc_lock_mode = 2

bind-address = 0.0.0.0

wsrep_provider = /usr/lib/libgalera_smm.so
wsrep_sst_method = rsync

# On galera-alpha only
wsrep_node_address = 192.168.56.101
wsrep_node_name = galera-alpha

# On galera-beta only
wsrep_node_address = 192.168.56.102
wsrep_node_name = galera-beta

# On galera-gamma only
wsrep_node_address = 192.168.56.103
wsrep_node_name = galera-gamma

Step 6: Bootstrap the Cluster

We can’t just start the service on all nodes simultaneously because they will all look for an existing cluster to join, fail to find one, and crash. We must designate one node to create the initial “Primary Component.”

The following steps should be done on Node 1 (galera-alpha) ONLY.

1. First, ensure the standard service is stopped: systemctl stop mariadb

2. Run the bootstrap command. This starts MariaDB in a special mode that initializes a new cluster UUID: galera_new_cluster

3. Verify the cluster is running: mariadb -e "SHOW STATUS LIKE 'wsrep_cluster_size';"

The value should be 1. If the value is 0 or the command fails, check the logs (journalctl -xeu mariadb.service) to ensure there are no configuration typos in the .cnf file.

Step 7: Join the Nodes

Now that the cluster exists, galera-beta and galera-gamma can join it. Because we listed their IPs in the wsrep_cluster_address configuration, they will automatically find the Primary node and sync up.

The following steps should be done on Node 2 (galera-beta) and Node 3 (galera-gamma) ONLY.

1. Restart the MariaDB service: systemctl restart mariadb.

2. Verify the cluster size on any machine: mariadb -e "SHOW STATUS LIKE 'wsrep_cluster_size';"

The value should now be 3.

Step 8: Manual Replication Test

Before we write any code, let’s verify that database replication is actually working.

1. On galera-alpha, create a database and a test table inside MariaDB:

CREATE DATABASE cluster_test;
USE cluster_test;
CREATE TABLE cats (id INT AUTO_INCREMENT PRIMARY KEY, name VARCHAR(50));
INSERT INTO cats (name) VALUES ('Izzy'), ('Milo');

2. On galera-beta or galera-gamma, check if the data arrived:

USE cluster_test;
SELECT * FROM cats;

If you see Izzy and Milo listed, congratulations! You have a working multi-master cluster.

Step 9: The Load Balancer Test (Node.js)

To truly see the power of the cluster, we need an application that can connect to all nodes, read/write data, and handle failover. We will write a simple Node.js script that acts as a “smart client,” rotating connections between our three servers.

Prepare the Database

Log into MariaDB on any of the nodes (since replication is active, it doesn’t matter which one) and run the following commands to set up the application schema:

CREATE DATABASE cluster_app;
USE cluster_app;

CREATE TABLE visits (
    id UUID NOT NULL DEFAULT uuid_v7(),
    node_name VARCHAR(50),
    PRIMARY KEY (id)
);

CREATE USER 'cluster_app_user'@'%' IDENTIFIED BY 'strong_password';
GRANT ALL PRIVILEGES ON cluster_app.* TO 'cluster_app_user'@'%';
FLUSH PRIVILEGES;

Set Up the Application

For this experiment, we will host the application on galera-alpha. In a real production environment, your application would live on a separate server, but this works for our experiment.

1. Install Node.js and npm: apt install -y nodejs npm

2. Initialize the project:

mkdir cluster-app
cd cluster-app
npm init -y
npm install mariadb

3. Create the script:

Create a file named index.js and paste in the following code. This script initializes a connection pool containing all three nodes. It creates a loop that performs a write operation followed by a read operation every 2 seconds, logging which physical server handled the request.

const mariadb = require("mariadb");

const DB_CREDENTIALS = {
  user: "cluster_app_user",
  password: "strong_password",
  database: "cluster_app",
  connectionLimit: 5,
};

const CLUSTER_NODES = [
  { id: "galera-alpha", host: "192.168.56.101" },
  { id: "galera-beta", host: "192.168.56.102" },
  { id: "galera-gamma", host: "192.168.56.103" },
];

const CHECK_INTERVAL_MS = 2000;

// Initialize the PoolCluster.
const cluster = mariadb.createPoolCluster();

// Add nodes to the cluster configuration
CLUSTER_NODES.forEach((node) => {
  cluster.add(node.id, { host: node.host, ...DB_CREDENTIALS });
  console.log(`Added node to pool: ${node.id} (${node.host})`);
});

async function performHealthCheck() {
  let conn;

  try {
    // Get a connection from a random node in the cluster
    // `null` here means to consider all nodes for the connection
    // `'RANDOM'` tells the connection to choose a random node
    conn = await cluster.getConnection(null, "RANDOM");

    // Identify which physical server we are connected to
    const hostnameRes = await conn.query("SELECT @@HOSTNAME AS server_id;");
    const serverName = hostnameRes[0].server_id;

    // Perform a Write Operation
    const insertRes = await conn.query(
      "INSERT INTO visits (node_name) VALUES (?) RETURNING id;",
      [serverName]
    );

    // Log success
    console.log(`Success on node: ${serverName} | ID: ${insertRes[0].id}`);

    // Perform a Read Operation
    const recentRes = await conn.query(
      "SELECT id, node_name FROM visits ORDER BY id DESC LIMIT 3;"
    );

    // Log recent visits
    console.log(recentRes);
  } catch (err) {
    console.error(`Connection Error:`, err.message);
  } finally {
    if (conn) conn.release();
  }
}

// Perform the health check every interval (2000ms)
const intervalId = setInterval(performHealthCheck, CHECK_INTERVAL_MS);

Run the Test

Start the application by running node index.js.

Watch the console output. You should see the application connecting to galera-alpha, galera-beta, and galera-gamma in a random fashion.

Added node to pool: galera-alpha (192.168.56.101)
Added node to pool: galera-beta (192.168.56.102)
Added node to pool: galera-gamma (192.168.56.103)
Success on node: galera-alpha | ID: 019b4b82-1d95-7464-8da8-cf72905a0f09
[
  {
    id: '019b4b82-1d95-7464-8da8-cf72905a0f09',
    node_name: 'galera-alpha'
  },
  {
    id: '019b4b80-c7a9-7844-9710-d69a9ca30855',
    node_name: 'galera-beta'
  },
  {
    id: '019b4b80-bfd9-76c8-9146-77531b6ec8d7',
    node_name: 'galera-gamma'
  }
]
Success on node: galera-beta | ID: 019b4b82-27ba-71d8-b94f-f9b06e0534d6
[
  {
    id: '019b4b82-27ba-71d8-b94f-f9b06e0534d6',
    node_name: 'galera-beta'
  },
  {
    id: '019b4b82-1d95-7464-8da8-cf72905a0f09',
    node_name: 'galera-alpha'
  },
  {
    id: '019b4b80-c7a9-7844-9710-d69a9ca30855',
    node_name: 'galera-beta'
  }
]

Create Some Chaos

While the script is running, try shutting down one of the nodes (e.g., go to VirtualBox and power off galera-beta) or stopping the MariaDB service (systemctl stop mariadb). You will see the application report a connection error briefly, and then immediately continue working by routing traffic to the remaining two nodes!

Conclusion

So, what have we actually accomplished here?

By pulling the plug on galera-beta while our script was running, we demonstrated High Availability (HA) in action. In a traditional single-node setup, that power outage would have meant a complete service stoppage, angry users, and frantic 3:00 AM phone calls.

In our cluster, the application hiccuped for a fraction of a second, realized the path was blocked, and immediately rerouted traffic to the healthy nodes (alpha and gamma). The data remained consistent, and the service remained online.

This type of architecture provides two massive benefits:

1. With a cluster, you have fault tolerance. Hardware fails. Updates go wrong. You can take a node offline for maintenance (or lose one to a disaster) without affecting your users.

2. While writes in a Galera cluster can be slightly slower (due to the overhead of syncing), your read capacity skyrockets. You can direct heavy reporting queries to one node while keeping another node free for fast user interactions.

In a true production environment, you would likely put a dedicated load balancer (like HAProxy or ProxySQL) in front of these nodes so your application only needs to know one IP address. But today, you’ve built the foundation: a self-healing, multi-master mesh that refuses to die.

Bonus: Recovering from a Full Outage

If all nodes go down (a full outage), you must follow a specific procedure to re-bootstrap and bring everything back up.

When the cluster crashes, Galera attempts to mark the last node that was running as “safe” to restart from. check the state file on all nodes:

cat /var/lib/mysql/grastate.dat

Look for the line safe_to_bootstrap: 1.

If you find a node with 1, run the bootstrap command only on that node:

galera_new_cluster

If none of the nodes are safe to bootstrap (none have 1), compare the seqno number in the files. Identify the node with the highest seqno number. On that node only, edit the /var/lib/mysql/grastate.dat file. Change, safe_to_bootstrap: 0 to safe_to_bootstrap: 1. Save the file. Then, bootstrap it with galera_new_cluster.

Verify the bootstrapped node has initialized the cluster:

mariadb -e "SHOW STATUS LIKE 'wsrep_cluster_size';"

The size should be 1.

You can start/restart the MariaDB service on the remaining nodes:

systemctl start mariadb

Check the cluster size once again:

mariadb -e "SHOW STATUS LIKE 'wsrep_cluster_size';"

It should now read 3. If you run into trouble, check the logs with journalctl -u mariadb -n 50.

Cover photo by BoliviaInteligente on Unsplash.
